QRC-FF-06-F-10LB-BT-W3
Stauff Mat. No. 6100175685
You have a regular demand for pipework equipment and hydraulic components and you are looking for individual pricing for our product range, please contact STAUFF.
Standard
ISO 16028
STAUFF Series
FF
(Port 1) Tube Outer Diameter / Series
10L
Product Type
Female body with valve
Valve Type
Flat Face
(Port 1) Connection Style
24° Inner Cone
Coupling system
Push to Connect
Nominal Size (DN)
06.3
Bulkhead Installation
yes
Material (Coupling)
Steel, Zinc-Nickel coated
Gross Weight
0.183 kg
Packaging unit
20 pieces
